0395145516 - 0395140002

0395145516

Active
Molex

TERM BLOCK PLUG 16POS 3.81MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsProduct SpecificationDatasheet
0395145516 - 0395140002

0395145516

Active
Molex

TERM BLOCK PLUG 16POS 3.81MM

Deep-Dive with AI

DocumentsProduct SpecificationDatasheet

Technical Specifications

Parameters and characteristics for this part

Specification0395145516
ColorGreen
Contact MaterialPhosphor Bronze
Contact Mating FinishGold
Current - UL8 A
FeaturesMating Flange
Material Flammability RatingUL94 V-0
Mounting TypeFree Hanging (In-Line)
Number of Levels1
Number of Positions16
Operating Temperature [Max]115 °C
Operating Temperature [Min]-40 °C
Pitch [x]0.15 in
Pitch [x]3.81 mm
Positions Per Level16
Screw SizeM2
Termination StyleScrew - Rising Cage Clamp
Torque - Screw0.23 Nm
Torque - Screw2 Lb-In
TypePlug, Female Sockets
Voltage - UL300 V
Wire Gauge or Range - AWG [Max]30 AWG
Wire Gauge or Range - AWG [Min]16 AWG

039514 Series

PartContact Mating FinishVoltage - ULTermination StyleColorCurrent - ULNumber of PositionsScrew SizeNumber of LevelsMounting TypeOperating Temperature [Min]Operating Temperature [Max]Torque - ScrewTorque - ScrewWire Gauge or Range - AWG [Max]Wire Gauge or Range - AWG [Min]FeaturesMaterial Flammability RatingPositions Per LevelContact MaterialPitch [x]Pitch [x]TypeNumber of Positions
Molex
0395140512
Gold
300 V
Screw - Rising Cage Clamp
Black
8 A
12
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
12
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395145018
Tin
300 V
Screw - Rising Cage Clamp
Green
8 A
18
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
18
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395145505
Gold
300 V
Screw - Rising Cage Clamp
Green
8 A
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
5
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395140208
Tin
300 V
Screw - Rising Cage Clamp
Black
8 A
8
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
Positions Stamped
UL94 V-0
8
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395140012
Tin
300 V
Screw - Rising Cage Clamp
Black
8 A
12
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
12
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395145512
Gold
300 V
Screw - Rising Cage Clamp
Green
8 A
12
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
12
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395145015
Tin
300 V
Screw - Rising Cage Clamp
Green
8 A
15
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
15
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395145516
Gold
300 V
Screw - Rising Cage Clamp
Green
8 A
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
16
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
16
Molex
0395140015
Tin
300 V
Screw - Rising Cage Clamp
Black
8 A
15
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
15
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets
Molex
0395145518
Gold
300 V
Screw - Rising Cage Clamp
Green
8 A
18
M2
1
Free Hanging (In-Line)
-40 °C
115 °C
0.23 Nm
2 Lb-In
30 AWG
16 AWG
Mating Flange
UL94 V-0
18
Phosphor Bronze
0.15 in
3.81 mm
Plug
Female Sockets

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 396$ 4.71

Description

General part information

039514 Series

16 Position Terminal Block Plug, Female Sockets 0.150" (3.81mm) 180° Free Hanging (In-Line)
