ODB6015-12HHB01A

Active

Orion Fans

FAN BLOWER 57.25X15.2MM 12VDC

Search across all available documentation for this part.

Active

Orion Fans

FAN BLOWER 57.25X15.2MM 12VDC

Technical Specifications

Parameters and characteristics for this part

Specification	ODB6015-12HHB01A

Air Flow	0.21 mł/min
Air Flow	7.5 CFM
Approval Agency	cURus, TUV
Bearing Type	Ball
Current Rating (Amps)	0.2 A
Fan Type	Blower
Features	Locked Rotor Sensor, Auto Restart
Lifetime @ Temp.	70000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	44 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	3.84 W
RPM	5000 RPM
Size / Dimension [x]	57.25 mm
Size / Dimension [z]	50.37 mm
Termination	3 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.2 VDC
Voltage Range [Min]	7 V
Width [y]	15.2 mm

Part	Bearing Type	Voltage Range [Max]	Voltage Range [Min]	Voltage - Rated	Features	Approval Agency	Termination	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Power (Watts)	Lifetime @ Temp.	Air Flow	Air Flow	Noise	Size / Dimension [x]	Size / Dimension [z]	RPM	Fan Type	Width [y]	Material - Blade	Current Rating (Amps)	Weight	Weight
Orion Fans ODB6015-12HHB01A	Ball	13.2 VDC	7 V	12 VDC	Auto Restart Locked Rotor Sensor	cURus TUV	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	3.84 W	70000 Hrs	0.21 mł/min	7.5 CFM	44 dB	57.25 mm	50.37 mm	5000 RPM	Blower	15.2 mm	Polybutylene Terephthalate (PBT)	0.2 A
Orion Fans ODB6015-12HHB02A	Ball	13.2 VDC	7 V	12 VDC	Locked Rotor Sensor	cURus TUV	3 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	3.84 W	70000 Hrs	0.207 mł/min	7.4 CFM	44 dB	57.25 mm	50.37 mm	5000 RPM	Blower	15.2 mm	Polybutylene Terephthalate (PBT)	0.2 A	34.93 g	0.077 lb

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	100	$ 10.82

General part information

Fan Blower 12VDC Rectangular/Rounded - 57.25mm L x 50.37mm H Ball 7.5 CFM (0.210m³/min) 3 Wire Leads
