TG-A1250-325-325-2.0

Obsolete

t-Global Technology

THERM PAD 325X325MM GREEN

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsThermal Pad Tolerance Datasheet

TG-A1250-325-325-2.0

Obsolete

t-Global Technology

THERM PAD 325X325MM GREEN

Deep-Dive with AI

DocumentsThermal Pad Tolerance Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TG-A1250-325-325-2.0

Color	Green
Material	Silicone
Outline [x]	325 mm
Outline [y]	325 mm
Shape	Square
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Thermal Conductivity	12.5 W/m-K
Thickness	0.079 in
Thickness	2 mm
Type	Gap Filler Pad, Sheet
Usage	Multi

TG-A1250 Series

Part	Shelf Life	Shape	Thermal Conductivity	Type	Material	Shelf Life Start	Color	Outline [y]	Outline [x]	Thickness	Thickness	Usage
t-Global Technology TG-A1250-15-15-3.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	15 mm	15 mm	3 mm	0.118 in	Multi
t-Global Technology TG-A1250-40-40-1.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	40 mm	40 mm	1 mm	0.0394 in	Multi
t-Global Technology TG-A1250-160-160-2.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	160 mm	160 mm	2 mm	0.079 in	Multi
t-Global Technology TG-A1250-100-100-1.5	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	100 mm	100 mm	1.5 mm	0.0591 "	Multi
t-Global Technology TG-A1250-15-15-1.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	15 mm	15 mm	1 mm	0.0394 in	Multi
t-Global Technology TG-A1250-10-10-1.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	10 mm	10 mm	1 mm	0.0394 in	Multi
t-Global Technology TG-A1250-20-20-1.5	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	20 mm	20 mm	1.5 mm	0.0591 "	Multi
t-Global Technology TG-A1250-325-325-2.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	325 mm	325 mm	2 mm	0.079 in	Multi
t-Global Technology TG-A1250-15-15-2.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	15 mm	15 mm	2 mm	0.079 in	Multi
t-Global Technology TG-A1250-160-160-2.5	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	160 mm	160 mm	2.5 mm	0.0984 in	Multi
