TG-A1250-100-100-1.5

Active

t-Global Technology

THERM PAD 100MMX100MM GREEN

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Thermal Pad Tolerance

TG-A1250-100-100-1.5

Active

t-Global Technology

THERM PAD 100MMX100MM GREEN

Deep-Dive with AI

DocumentsDatasheet Thermal Pad Tolerance

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TG-A1250-100-100-1.5

Color	Green
Material	Silicone
Outline [x]	100 mm
Outline [y]	100 mm
Shape	Square
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Thermal Conductivity	12.5 W/m-K
Thickness	1.5 mm
Thickness	0.0591 "
Type	Gap Filler Pad, Sheet
Usage	Multi

TG-A1250 Series

Part	Shelf Life	Shape	Thermal Conductivity	Type	Material	Shelf Life Start	Color	Outline [y]	Outline [x]	Thickness	Thickness	Usage
t-Global Technology TG-A1250-15-15-3.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	15 mm	15 mm	3 mm	0.118 in	Multi
t-Global Technology TG-A1250-40-40-1.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	40 mm	40 mm	1 mm	0.0394 in	Multi
t-Global Technology TG-A1250-160-160-2.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	160 mm	160 mm	2 mm	0.079 in	Multi
t-Global Technology TG-A1250-100-100-1.5	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	100 mm	100 mm	1.5 mm	0.0591 "	Multi
t-Global Technology TG-A1250-15-15-1.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	15 mm	15 mm	1 mm	0.0394 in	Multi
t-Global Technology TG-A1250-10-10-1.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	10 mm	10 mm	1 mm	0.0394 in	Multi
t-Global Technology TG-A1250-20-20-1.5	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	20 mm	20 mm	1.5 mm	0.0591 "	Multi
t-Global Technology TG-A1250-325-325-2.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	325 mm	325 mm	2 mm	0.079 in	Multi
t-Global Technology TG-A1250-15-15-2.0	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	15 mm	15 mm	2 mm	0.079 in	Multi
t-Global Technology TG-A1250-160-160-2.5	24 Months	Square	12.5 W/m-K	Gap Filler Pad Sheet	Silicone	Date of Manufacture	Green	160 mm	160 mm	2.5 mm	0.0984 in	Multi

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 39.95
		10	$ 37.60
		25	$ 35.25
		50	$ 32.90
		100	$ 31.72
		250	$ 29.96
