0150310615

Active

Molex

CABLE FFC/FPC 15POS 0.3MM 6"

Search across all available documentation for this part.

Active

Molex

CABLE FFC/FPC 15POS 0.3MM 6"

Technical Specifications

Parameters and characteristics for this part

Specification	0150310615

Cable Type	FPC, FFC
Length	152.4 mm
Length	6 in
Length - Exposed Ends [x]	0.079 in
Length - Exposed Ends [x]	2 mm
Number of Conductors	15
Pitch [x]	0.012 in
Pitch [x]	0.3 mm
Termination Style	Backers on Both Sides, Top on Both Sides

Part	Cable Type	Pitch [x]	Pitch [x]	Length - Exposed Ends [x]	Length - Exposed Ends [x]	Length	Length	Termination Style	Number of Conductors	Length [x]
Molex 0150310807	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	8 in	203.2 mm	Backers on Both Sides Top on Both Sides	7
Molex 0150310831	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	8 in	203.2 mm	Backers on Both Sides Top on Both Sides	31
Molex 0150310207	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	2 in	50.8 mm	Backers on Both Sides Top on Both Sides	7
Molex 0150310815	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	8 in	203.2 mm	Backers on Both Sides Top on Both Sides	15
Molex 0150310615	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	6 in	152.4 mm	Backers on Both Sides Top on Both Sides	15
Molex 0150311007	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm		254 mm	Backers on Both Sides Top on Both Sides	7	10 in
Molex 0150311015	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm		254 mm	Backers on Both Sides Top on Both Sides	15	10 in
Molex 0150310811	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	8 in	203.2 mm	Backers on Both Sides Top on Both Sides	11
Molex 0150310233	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	2 in	50.8 mm	Backers on Both Sides Top on Both Sides	33
Molex 0150310433	FFC FPC	0.012 in	0.3 mm	0.079 in	2 mm	4 in	101.6 mm	Backers on Both Sides Top on Both Sides	33

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

15 Position FFC, FPC Cable 0.012" (0.30mm) 6.000" (152.40mm)
