RAVHD19

Obsolete

Switchcraft Inc.

CONN HDMI TYPE A F 19 POS 0.57MM SOLDER ST THRU-HOLE 19 TERMINAL 1 PORT TRAY

Search across all available documentation for this part.

Obsolete

Switchcraft Inc.

CONN HDMI TYPE A F 19 POS 0.57MM SOLDER ST THRU-HOLE 19 TERMINAL 1 PORT TRAY

Technical Specifications

Parameters and characteristics for this part

Part	Number of Ports	Mounting Type	Shell/Shielding Material	Current Rating (Amps)	Number of Contacts [custom]	Mounting Feature	Mating Cycles	Gender	Contact Finish	Termination	Specifications	Insulation Color	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Connector Type	Features
Switchcraft Inc. RAVHD19ETR	1	Through Hole Right Angle	Brass	0.5 A	19	Flag Vertical	5000	Receptacle	Gold	Solder	HDMI 2.0	Black	Shielded	-25 °C	85 °C	40 V	HDMI
Switchcraft Inc. RAVHD19	1	Through Hole Right Angle	Brass	0.5 A	19	Flag Vertical	5000	Receptacle	Gold	Solder	HDMI 2.0	Black	Shielded	-25 °C	85 °C	40 V	HDMI	Board Guide

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

HDMI HDMI 2.0 Receptacle Connector 19 Position Through Hole, Right Angle

Technical documentation and resources

No documents available
