0349590384

Active

Molex

MINI50 CONN RCPT 38CKT CPA GRY P

Deep-Dive with AI

Search across all available documentation for this part.

0349590384

Active

Molex

MINI50 CONN RCPT 38CKT CPA GRY P

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	0349590384

null

034959 Series

Part	Contact Type	Pitch [x]	Pitch [x]	Contact Termination	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows	Insulation Material	Fastening Type	Color	Note	Mounting Type	Number of Positions	Features	Row Spacing	Row Spacing
Molex 0349590340	Female Socket	0.079 in	2 mm	Crimp	Receptacle	-40 °C	105 ░C	3	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Black	Contacts Not Included	Free Hanging (In-Line)	34	Connector Position Assurance (CPA)
Molex 0349590384
Molex 0349590388	Female Socket	0.079 in	2 mm	Crimp	Receptacle			3		Latch Lock	Gray	Contacts Not Included	Free Hanging (In-Line)	38
Molex 0349590341	Female Socket	0.079 in	2 mm	Crimp	Receptacle	-40 °C	105 ░C	3	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Gray	Contacts Not Included	Free Hanging (In-Line)	34	Connector Position Assurance (CPA)
Molex 0349590342	Female Socket	0.079 in	2 mm	Crimp	Receptacle	-40 °C	105 ░C	3	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Gray	Contacts Not Included	Free Hanging (In-Line)	34	Connector Position Assurance (CPA)
Molex 0349590391	Female Socket	0.079 in	2 mm	Crimp	Receptacle			3	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Gray	Contacts Not Included	Free Hanging (In-Line)	38
Molex 0349591340	Female Socket	0.079 in	2 mm	Crimp	Receptacle			2	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Black		Free Hanging (In-Line)	34		0.157 in	4 mm
Molex 0349590348	Female Socket	0.079 in	2 mm	Crimp	Receptacle	-40 °C	105 ░C	3	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Gray	Contacts Not Included	Free Hanging (In-Line)	34
Molex 0349590392	Female Socket	0.079 in	2 mm	Crimp	Receptacle	-40 °C	105 ░C	3	Polyamide (PA66) Nylon 6/6 Glass Filled	Latch Lock	Gray		Free Hanging (In-Line)	38	Sealed

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 2.65
		10	$ 2.25
		25	$ 2.11
		70	$ 1.96
		140	$ 1.87
		280	$ 1.78
		560	$ 1.69
		1050	$ 1.62
		2520	$ 1.52

Description

General part information

034959 Series

Rectangular Connectors - Housings

Documents

Technical documentation and resources

No documents available
