APV-8-5

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC 5V 1.4A

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC 5V 1.4A

Technical Specifications

Parameters and characteristics for this part

Part	Number of Outputs	Efficiency	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Features	Voltage - Output	Ratings	Mounting Type	Termination Style	Current - Output (Max) [Max]	Topology	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Voltage - Input (Min) [Min]	Voltage - Isolation	Type	Voltage - Input (Max) [Max]
MEAN WELL USA Inc. APV-8-5	1	74 %	7 W	70 °C	-30 ░C	CCC CE cURus	OCP OVP SCP	5 V	IP42	Chassis Mount	Wire Leads	1.4 A	AC DC Converter	2.36 in	60 mm	30 mm	1.18 in	0.93 in	23.5 mm	90 VAC	3750 V	Constant Voltage	264 VAC
MEAN WELL USA Inc. APV-8E-12	1	77.5 %	8 W	70 °C	-30 ░C	CB CE ENEC	OCP OVP SCP	12 V	IP42	Chassis Mount	Wire Leads	670 mA	AC DC Converter	2.36 in	60 mm	30 mm	1.18 in	0.93 in	23.5 mm	180 VAC	3750 V	Constant Voltage	264 VAC
MEAN WELL USA Inc. APV-8E-5	1	74 %	7 W	70 °C	-30 ░C	CB CE ENEC	OCP OVP SCP	5 V	IP42	Chassis Mount	Wire Leads	1.4 A	AC DC Converter	2.36 in	60 mm	30 mm	1.18 in	0.93 in	23.5 mm	180 VAC	3750 V	Constant Voltage	264 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1.4A 5V Constant Voltage LED Driver AC DC Converter Topology 1 Output
