MID-30A
ActiveOptiFuse
FUSE AUTO 30A 32VDC AUTO LINK
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MID-30A
ActiveOptiFuse
FUSE AUTO 30A 32VDC AUTO LINK
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MID-30A |
|---|---|
| Breaking Capacity @ Rated Voltage | 1 kA |
| Current Rating (Amps) | 30 A |
| Fuse Type | Automotive |
| Mounting Type | Bolt Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Auto Link |
| Response Time | Fast Blow |
| Size / Dimension [x] | 0.63 " |
| Size / Dimension [x] | 16 mm |
| Size / Dimension [y] | 0.472 " |
| Size / Dimension [y] | 12 mm |
| Size / Dimension [z] | 0.323 " |
| Size / Dimension [z] | 8.2 mm |
| Voltage Rating - DC | 32 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3.29 | |
| 10 | $ 3.18 | |||
| 25 | $ 3.06 | |||
| 50 | $ 2.35 | |||
| 100 | $ 1.97 | |||
| 250 | $ 1.86 | |||
| 500 | $ 1.60 | |||
| 1000 | $ 1.52 | |||
Description
General part information
MID Series
30 A AC 32 V DC Fuse Automotive Bolt Mount Auto Link
