XTR111AIDRCR
ActiveVOLTAGE-TO-CURRENT CONVERTER/TRANSMITTER WITH 3-V TO 15-V REGULATOR AND RESISTOR SET I/O RATIO
Deep-Dive with AI
Search across all available documentation for this part.
XTR111AIDRCR
ActiveVOLTAGE-TO-CURRENT CONVERTER/TRANSMITTER WITH 3-V TO 15-V REGULATOR AND RESISTOR SET I/O RATIO
Technical Specifications
Parameters and characteristics for this part
| Specification | XTR111AIDRCR |
|---|---|
| Current - Supply | 550 µA |
| Input Type | Voltage |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Output Type | Current |
| Package / Case | 10-VFDFN Exposed Pad |
| Supplier Device Package | 10-VSON (3x3) |
| Type | Current Transmitter |
XTR111 Series
Voltage-to-current converter/transmitter with 3-V to 15-V regulator and resistor set I/O ratio
| Part | Package / Case | Package / Case | Current - Supply | Mounting Type | Input Type | Supplier Device Package | Type | Output Type | Operating Temperature [Min] | Operating Temperature [Max] | Utilized IC / Part | Supplied Contents | Embedded | Primary Attributes [Max] | Primary Attributes [Min] | Function | Secondary Attributes [Max] | Secondary Attributes [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments | 10-MSOP 10-PowerTFSOP | 0.118 in 3 mm | 550 µA | Surface Mount | Voltage | 10-HVSSOP | Current Transmitter | Current | -55 °C | 125 °C | ||||||||
Texas Instruments | Power Management | XTR111 | Board(s) | 5 V 20 mA | 0 V 0 mA | Voltage to Current | 40 V | 8 V | ||||||||||
Texas Instruments | 10-VFDFN Exposed Pad | 550 µA | Surface Mount | Voltage | 10-VSON (3x3) | Current Transmitter | Current | -55 °C | 125 °C | |||||||||
Texas Instruments | 10-MSOP 10-PowerTFSOP | 0.118 in 3 mm | 550 µA | Surface Mount | Voltage | 10-HVSSOP | Current Transmitter | Current | -55 °C | 125 °C | ||||||||
Texas Instruments | 10-MSOP 10-PowerTFSOP | 0.118 in 3 mm | 550 µA | Surface Mount | Voltage | 10-HVSSOP | Current Transmitter | Current | -55 °C | 125 °C | ||||||||
Texas Instruments | 10-MSOP 10-PowerTFSOP | 0.118 in 3 mm | 550 µA | Surface Mount | Voltage | 10-HVSSOP | Current Transmitter | Current | -55 °C | 125 °C | ||||||||
Texas Instruments | 10-VFDFN Exposed Pad | 550 µA | Surface Mount | Voltage | 10-VSON (3x3) | Current Transmitter | Current | -55 °C | 125 °C | |||||||||
Texas Instruments | Power Management | XTR111 | Board(s) | 4 V 20 mA | 0 V 0 mA | Voltage to Current | 40 V | 8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.87 | |
| 10 | $ 1.68 | |||
| 25 | $ 1.59 | |||
| 100 | $ 1.35 | |||
| 250 | $ 1.27 | |||
| 500 | $ 1.11 | |||
| 1000 | $ 0.92 | |||
| Digi-Reel® | 1 | $ 1.87 | ||
| 10 | $ 1.68 | |||
| 25 | $ 1.59 | |||
| 100 | $ 1.35 | |||
| 250 | $ 1.27 | |||
| 500 | $ 1.11 | |||
| 1000 | $ 0.92 | |||
| Tape & Reel (TR) | 3000 | $ 0.86 | ||
| 6000 | $ 0.83 | |||
| Newark | Each (Supplied on Cut Tape) | 1 | $ 2.29 | |
| 10 | $ 2.18 | |||
| 25 | $ 2.08 | |||
| 50 | $ 1.99 | |||
| 100 | $ 1.90 | |||
| 250 | $ 1.84 | |||
| 500 | $ 1.80 | |||
| 1000 | $ 1.77 | |||
| Texas Instruments | LARGE T&R | 1 | $ 1.41 | |
| 100 | $ 1.16 | |||
| 250 | $ 0.84 | |||
| 1000 | $ 0.63 | |||
Description
General part information
XTR111 Series
The XTR111 is a precision voltage-to-current converter designed for the standard 0mA to 20mA or 4mA to 20mA analog signals, and sources up to 32mA. The ratio between input voltage and output current is set by a single resistor, RSET. The circuit can also be modified for voltage-output operation.
An external P-MOSFET transistor provides high output resistance and a broad-compliance voltage range that extends from 2V less than the supply voltage, VVSP, to voltages far less than ground.
The adjustable 3V to 15V subregulator output provides the supply voltage for additional circuitry.
