S1642

Active

LAPP

CABLE GLAND 28-39MM M63 POLYAMID

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

S1642

Active

LAPP

CABLE GLAND 28-39MM M63 POLYAMID

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	S1642

Color	Gray
Ingress Protection	NEMA 1, IP69, IP68, NEMA 12
Material	Polyamide (PA), Nylon
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Outside Cable Diameter (Max) [Max] [diameter]	39 mm
Outside Cable Diameter (Max) [Max] [diameter]	1.535 in
Outside Cable Diameter (Min) [Min]	1.102 in
Outside Cable Diameter (Min) [Min]	28 mm
Thread Length	0.472 in
Thread Length	12 mm
Type	Cable Gland

- Series

Part	Material	Operating Temperature [Max]	Operating Temperature [Min]	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Max) [Max] [diameter]	Type	Thread Size	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min)	Thread Length	Thread Length	Color	Ingress Protection	Outside Cable Diameter (Min) [Min]	Outside Cable Diameter (Min) [Min]	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Max) [Max]	Outside Cable Diameter (Max) [Max]
LAPP S1134	Polyamide (PA) Nylon	100 °C	-40 °C	0.709 in	18.01 mm	Cable Gland	3/4 NPT	0.512 in	13 mm	0.591 in	15 mm	Gray
LAPP S1609	Polyamide (PA) Nylon	100 °C	-40 °C	0.276 in	7 mm	Cable Gland	M16x1.5			0.315 in	8 mm	Gray	IP68 IP69 NEMA 1 NEMA 12	3.5 mm	0.138 in
LAPP S1148	Polyamide (PA) Nylon	100 °C	-40 °C			Cable Gland	PG48	1.535 in		0.551 in	14 mm	Gray				39 mm	44 mm	1.732 in
LAPP S1101	Polyamide (PA) Nylon	100 °C	-40 °C	1 "	25.4 mm	Cable Gland	1" NPT	0.748 in		0.591 in	15 mm	Gray				19 mm
LAPP S1636	Polyamide (PA) Nylon	100 °C	-40 °C	1.142 in	29 mm	Cable Gland	M50x1.5	0.945 in		0.472 in	12 mm	Gray	IP68 IP69 NEMA 1 NEMA 12			24 mm
LAPP S2134	Polyamide (PA) Nylon	100 °C	-40 °C	0.709 in	18.01 mm	Cable Gland	3/4 NPT	0.512 in	13 mm	0.591 in	15 mm	Black
LAPP S1112	Polyamide (PA) Nylon	100 °C	-40 °C	0.472 in	12 mm	Cable Gland	1/2" NPT			0.591 in	15 mm	Gray		5 mm	0.197 in
LAPP S1642	Polyamide (PA) Nylon	100 °C	-40 °C	1.535 in	39 mm	Cable Gland				0.472 in	12 mm	Gray	IP68 IP69 NEMA 1 NEMA 12	28 mm	1.102 in
LAPP S1236	Polyamide (PA) Nylon	100 °C	-40 °C	1.024 "	26 mm	Cable Gland	PG36			0.512 in	13 mm	Gray
LAPP S1116	Polyamide (PA) Nylon	100 °C	-40 °C			Cable Gland	PG16	0.354 in		0.394 in	10 mm	Gray				9 mm	14 mm	0.551 "

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 31.64

Description

General part information

- Series

Cable Gland Polyamide (PA), Nylon M63x1.5 Gray
