USBFTV2PE1N

Active

Amphenol Socapex

ADAPTER USB A RCPT TO USB A RCPT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsUSBF TV Series

USBFTV2PE1N

Active

Amphenol Socapex

ADAPTER USB A RCPT TO USB A RCPT

Deep-Dive with AI

DocumentsUSBF TV Series

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	USBFTV2PE1N

Convert From (Adapter End)	USB-A (USB TYPE-A), Receptacle
Convert To (Adapter End)	USB-A (USB TYPE-A), Receptacle
Mounting Type	Panel Mount, Screw Hole

USBFTV2 Series

Part	Shielding	Wire Gauge	Features	Configuration	Specifications	Length [x]	Length [x]	Transfer Rate	Mounting Type	Convert From (Adapter End)	Convert To (Adapter End)	Termination	Mounting Feature	Operating Temperature [Max]	Operating Temperature [Min]	Gender	Ingress Protection	Mating Cycles	Shell/Shielding Material	Number of Ports	Connector Type	Number of Contacts [custom]
Amphenol Socapex USBFTV2SA2BZC03A	Shielded	24 AWG 28 AWG	Data Transfer and Charge Industrial Environments - IP68 Panel Mount	A Female to A Male (Circular Coupling)	USB 2.0	0.98 ft	300 mm	480 Mbps
Amphenol Socapex USBFTV2PE1N									Panel Mount Screw Hole	USB-A (USB TYPE-A) Receptacle	Receptacle USB-A (USB TYPE-A)
Amphenol Socapex USBFTV2PE2G			Backshell Circular Threaded Coupling		USB 2.0							Solder	Flange	85 °C	-40 °C	Receptacle	IP68 - Dust Tight Waterproof	500	Aluminum	1	USB-A (USB TYPE-A)	4
Amphenol Socapex USBFTV2PEMSA2N10OPEN	Shielded	24 AWG 28 AWG	Data Transfer and Charge Industrial Environments - IP68 Panel Mount	A Female to Cable Round (Circular Coupling)	USB 2.0	3.28 ft	1 m	480 Mbps
Amphenol Socapex USBFTV2PEM2N			Backshell Circular Threaded Coupling		USB 2.0							Solder	Flange	85 °C	-40 °C	Receptacle	IP68 - Dust Tight Waterproof	500	Aluminum	1	USB-A (USB TYPE-A)	4
Amphenol Socapex USBFTV2SA2G10A	Shielded	24 AWG 28 AWG	Data Transfer and Charge Industrial Environments - IP68 Panel Mount	A Female to A Male (Circular Coupling)	USB 2.0	3.28 ft	1 m	480 Mbps
Amphenol Socapex USBFTV22N			Circular Threaded Coupling		USB 2.0							Solder	Flange	85 °C	-40 °C	Receptacle	IP68 - Dust Tight Waterproof	500	Aluminum	1	USB-A (USB TYPE-A)	4
Amphenol Socapex USBFTV22G			Circular Threaded Coupling		USB 2.0							Solder	Flange	85 °C	-40 °C	Receptacle	IP68 - Dust Tight Waterproof	500	Aluminum	1	USB-A (USB TYPE-A)	4
Amphenol Socapex USBFTV2SA2N03A	Shielded	24 AWG 28 AWG	Data Transfer and Charge Industrial Environments - IP68 Panel Mount	A Female to A Male (Circular Coupling)	USB 2.0	0.98 ft	300 mm	480 Mbps
Amphenol Socapex USBFTV21BZC									Panel Mount Screw Hole	USB-A (USB TYPE-A) Receptacle	Receptacle USB-A (USB TYPE-A)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 148.30
		10	$ 136.09
		25	$ 130.85
		50	$ 126.49

Description

General part information

USBFTV2 Series

Adapter Connector USB-A (USB TYPE-A), Receptacle To USB-A (USB TYPE-A), Receptacle Panel Mount, Screw Hole

Documents

Technical documentation and resources

USBF TV Series

Datasheet
