SSI-LXR1612SRD

Active

Lumex Opto/Components Inc.

LED 3MM FLUSH SUP RED DIFF PNLMT

Search across all available documentation for this part.

Active

Lumex Opto/Components Inc.

LED 3MM FLUSH SUP RED DIFF PNLMT

Technical Specifications

Parameters and characteristics for this part

Part	Type	Wavelength - Peak	Viewing Angle	Panel Cutout Dimensions	Panel Cutout Dimensions	Millicandela Rating	Panel Cutout Shape	Lens Size	Lens Size	Lens Transparency	Current	Lamp Color	Voltage	Lens Color	Termination Style	Lens Style
Lumex Opto/Components Inc. SSI-LXR1612SRD	LED	660 nm	30 °	6.1 mm	0.24 in	80 mcd	Round	3 mm	T-1	Diffused	30 mA	Red	1.8 V	Red
Lumex Opto/Components Inc. SSI-LXR1612GD-150	LED	565 nm	60 °	6.1 mm	0.24 in	30 mcd	Round	3 mm	T-1	Diffused	25 mA	Green	2.2 V	Green
Lumex Opto/Components Inc. SSI-LXR1612GD-250	LED	565 nm	60 °			30 mcd	Round	3 mm	T-1	Diffused		Green	2.2 V	Green	Wire Leads - 9.8" (248.92mm)	Round with Domed Top
Lumex Opto/Components Inc. SSI-LXR1612ID	LED	635 nm	60 °	6.1 mm	0.24 in	30 mcd	Round	3 mm	T-1	Diffused	30 mA	Red	2 V	Red
Lumex Opto/Components Inc. SSI-LXR1612ID-150	LED	635 nm	60 °			30 mcd	Round	3 mm	T-1	Diffused	30 mA	Red	2 V	Red	Wire Leads - 6.000" (152.40mm)	Round with Domed Top
Lumex Opto/Components Inc. SSI-LXR1612SRD12V6

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Panel Indicator Red Diffused 30° 1.8V 30mA

Technical documentation and resources

No documents available
