A1123-HSL.GN

Active

Sunon Fans

FAN AXIAL 119.5X38.5MM 115VAC

Search across all available documentation for this part.

Active

Sunon Fans

FAN AXIAL 119.5X38.5MM 115VAC

Technical Specifications

Parameters and characteristics for this part

Specification	A1123-HSL.GN

Air Flow	3.22 mł/min
Air Flow	115 CFM
Approval Agency	TUV, cUR, UL, CE
Bearing Type	Sleeve
Current Rating (Amps)	0.21 A
Fan Type	Tubeaxial
Material - Blade	Polybutylene Terephthalate (PBT)
Material - Frame	Aluminum
Noise	49 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	20 W
RPM	3100 RPM
Size / Dimension [x]	119.5 mm
Size / Dimension [z]	119.5 mm
Static Pressure	94.6 Pa
Static Pressure	0.38 in H2O
Termination	2 Wire Leads
Voltage - Rated	115 VAC
Voltage Range [Max]	125 VAC
Voltage Range [Min]	75 VAC
Width [y]	38.5 mm

Part	Noise	Voltage - Rated	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Fan Type	Termination	Material - Frame	Size / Dimension [z]	Size / Dimension [x]	Approval Agency	Width [y]	Material - Blade	Current Rating (Amps)	Bearing Type	RPM	Air Flow	Air Flow	Power (Watts)	Static Pressure	Static Pressure	Voltage Range [Min]	Voltage Range [Max]
Sunon Fans A1123-HBT.GN	50 dB(A)	115 VAC	70 °C	70 °C	-10 °C	-10 °C	Tubeaxial	2 Terminals	Aluminum	119.5 mm	119.5 mm	CE cUR TUV UL	38.5 mm	Polybutylene Terephthalate (PBT)	0.25 A	Ball	3100 RPM	3.28 m³/min	117 CFM	20 W	0.39 in H2O	97.1 Pa	75 VAC	125 VAC
Sunon Fans A1123-HSL.GN	49 dB	115 VAC	70 °C	70 °C	-10 °C	-10 °C	Tubeaxial	2 Wire Leads	Aluminum	119.5 mm	119.5 mm	CE cUR TUV UL	38.5 mm	Polybutylene Terephthalate (PBT)	0.21 A	Sleeve	3100 RPM	3.22 mł/min	115 CFM	20 W	0.38 in H2O	94.6 Pa	75 VAC	125 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	40	$ 25.22

General part information

Fan Tubeaxial 115VAC Square - 119.5mm L x 119.5mm H Sleeve 115.0 CFM (3.22m³/min) 2 Wire Leads
