97-3100A-24-11S

Active

Amphenol Industrial Operations

CONN RCPT FMALE 9P SOLDER CUP

Search across all available documentation for this part.

Active

Amphenol Industrial Operations

CONN RCPT FMALE 9P SOLDER CUP

Technical Specifications

Parameters and characteristics for this part

Specification	97-3100A-24-11S

Applications	Industrial, Automotive
Color	Olive Drab
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Silver
Contact Material	Copper Alloy
Features	Backshell
Insert Material	Diallyl Phthalate (DAP)
Mounting Feature	Flange
Number of Positions	9
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Orientation	N
Primary Material	Metal
Shell Finish	Olive Drab Chromate over Cadmium
Shell Material	Aluminum Alloy
Shell Size - Insert	24-11
Shielding	Unshielded

Part	Mounting Feature	Shell Finish	Connector Type	Primary Material	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Shielding	Shell Size - Insert [Max]	Shell Size - Insert [Min]	Contact Finish - Mating	Shell Material	Contact Material	Orientation	Features	Applications	Insert Material	Color	Shell Size - Insert
Amphenol Industrial Operations 97-3100A-24-28P	Flange	Olive Drab Chromate over Cadmium	Male Pins Receptacle	Metal	-55 °C	125 °C	24	Unshielded	28	24	Silver	Aluminum Alloy	Copper Alloy	N	Backshell	Automotive Industrial	Diallyl Phthalate (DAP)	Olive Drab
Amphenol Industrial Operations 97-3100A-24-11S	Flange	Olive Drab Chromate over Cadmium	Receptacle Female Sockets	Metal	-55 °C	125 °C	9	Unshielded			Silver	Aluminum Alloy	Copper Alloy	N	Backshell	Automotive Industrial	Diallyl Phthalate (DAP)	Olive Drab	24-11

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

9 Position Circular Connector Receptacle, Female Sockets Solder Cup
