C1362.21.90
ActivePrysmian Group
CABLE SPKR 2COND 22AWG CLEAR
Deep-Dive with AI
Search across all available documentation for this part.
C1362.21.90
ActivePrysmian Group
CABLE SPKR 2COND 22AWG CLEAR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | C1362.21.90 |
|---|---|
| Cable Type | Speaker |
| Conductor Material | Copper, Tinned, Copper, Bare |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 30 AWG |
| Jacket (Insulation) Diameter [diameter] | 0.145 in |
| Jacket (Insulation) Diameter [diameter] | 3.68 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.02 in |
| Jacket (Insulation) Thickness | 0.508 mm |
| Jacket Color | Clear |
| Length | 1000 ft |
| Length | 304.8 m, 15.24 m |
| Length [x] | 50 ft |
| Number of Conductors | 2 |
| Usage | Home, Audio-Video |
| Voltage | 120 V |
| Wire Gauge | 22 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1 | $ 13.86 | |
| 5 | $ 11.34 | |||
| 10 | $ 8.82 | |||
| 1000 | $ 0.11 | |||
| 2000 | $ 0.11 | |||
| 3000 | $ 0.10 | |||
| 5000 | $ 0.10 | |||
| 7000 | $ 0.10 | |||
| 10000 | $ 0.10 | |||
| 25000 | $ 0.09 | |||
| 50000 | $ 0.09 | |||
| 100000 | $ 0.08 | |||
Description
General part information
C1362 Series
2 Conductor Speaker Cable Clear 22 AWG 1000.0' (304.8m)
Documents
Technical documentation and resources
No documents available
