FPG.00.304.CLAD35
ActiveLEMO
CONN PLUG MALE 4P GOLD SLDR CUP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FPG.00.304.CLAD35
ActiveLEMO
CONN PLUG MALE 4P GOLD SLDR CUP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FPG.00.304.CLAD35 |
|---|---|
| Backshell Material, Plating | Brass, Chrome |
| Cable Opening [diameter] | 3.5 mm |
| Cable Opening [diameter] | 0.138 in, 0.106 in |
| Cable Opening [diameter] | 2.7 mm |
| Color | Silver |
| Connector Type | Plug, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 1 µm |
| Contact Finish Thickness - Mating | 39.4 µin |
| Contact Material | Brass |
| Current Rating (Amps) | 2 A |
| Fastening Type | Push-Pull |
| Features | Backshell |
| Ingress Protection | IP50 |
| Insert Material | Polyetheretherketone (PEEK) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Number of Positions | 4 |
| Operating Temperature [Max] | 250 °C |
| Operating Temperature [Min] | -55 °C |
| Orientation | G |
| Primary Material | Metal |
| Shell Finish | Chrome |
| Shell Material | Brass |
| Shell Size - Insert | 304 |
| Shielding | Shielded |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 46.36 | |
| 10 | $ 42.54 | |||
| 25 | $ 40.90 | |||
| 50 | $ 39.54 | |||
| 100 | $ 37.36 | |||
| 250 | $ 36.27 | |||
Description
General part information
FPG.00.304 Series
4 Position Circular Connector Plug, Male Pins Solder Cup
