R213665000W

Active

Radiall USA, Inc.

MCX / RIGHT ANGLE JACK RECEPTACL

Search across all available documentation for this part.

Active

Radiall USA, Inc.

MCX / RIGHT ANGLE JACK RECEPTACL

Technical Specifications

Parameters and characteristics for this part

Specification	R213665000W

Body Finish	Gold
Body Material	Brass
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	MCX
Connector Type	Female Socket, Jack
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Snap-On
Frequency - Max [Max]	6000 MHz
Housing Color	Gold
Impedance	75 Ohms
Mating Cycles	500
Mounting Type	Through Hole, Right Angle
Number of Ports	1
Operating Temperature [Max]	155 °C
Operating Temperature [Min]	-55 °C
Shield Termination	Solder
Voltage Rating	335 V

Part	Housing Color	Impedance	Number of Ports	Mating Cycles	Operating Temperature [Max]	Operating Temperature [Min]	Dielectric Material	Frequency - Max [Max]	Center Contact Material	Mounting Type	Voltage Rating	Shield Termination	Contact Termination	Connector Style	Connector Type	Body Finish	Body Material	Center Contact Plating	Fastening Type
Radiall USA, Inc. R213665000	Gold	75 Ohms	1	500	155 °C	-55 °C	Polytetrafluoroethylene (PTFE)	6000 MHz	Beryllium Copper	Through Hole Right Angle	335 V	Solder	Solder	MCX	Female Socket Jack	Gold	Brass	Gold	Snap-On
Radiall USA, Inc. R213664800	Gold	75 Ohms	1	500	155 °C	-55 °C	Polytetrafluoroethylene (PTFE)	6000 MHz	Beryllium Copper	Surface Mount Right Angle	335 V	Solder	Solder	MCX	Female Socket Receptacle	Gold	Brass	Gold	Snap-On
Radiall USA, Inc. R213664800W	Gold	75 Ohms	1	500	155 °C	-55 °C	Polytetrafluoroethylene (PTFE)	6000 MHz	Beryllium Copper	Surface Mount Right Angle	335 V	Solder	Solder	MCX	Female Socket Receptacle	Gold	Brass	Gold	Snap-On
Radiall USA, Inc. R213665000W	Gold	75 Ohms	1	500	155 °C	-55 °C	Polytetrafluoroethylene (PTFE)	6000 MHz	Beryllium Copper	Through Hole Right Angle	335 V	Solder	Solder	MCX	Female Socket Jack	Gold	Brass	Gold	Snap-On

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	25	$ 15.30

General part information

MCX Connector Jack, Female Socket 75 Ohms Through Hole, Right Angle Solder
