MPQ2166GD-AEC1-Z
ActiveMONOLITHIC POWER SYSTEMS (MPS)
IC REG BUCK ADJ 2A/2A DL 18QFN
Deep-Dive with AI
Search across all available documentation for this part.
MPQ2166GD-AEC1-Z
ActiveMONOLITHIC POWER SYSTEMS (MPS)
IC REG BUCK ADJ 2A/2A DL 18QFN
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MPQ2166GD-AEC1-Z |
|---|---|
| Current - Output [x] | 3 A, 2 A |
| Current - Output [y] | 1 A, 2 A |
| Frequency - Switching [Max] | 3 MHz |
| Function | Step-Down |
| Grade | Automotive |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Package / Case | 18-VFQFN |
| Qualification | AEC-Q100 |
| Supplier Device Package | 18-QFN (2x3) |
| Synchronous Rectifier | True |
| Topology | Buck |
| Voltage - Input (Max) [Max] | 6 V |
| Voltage - Input (Min) [Min] | 2.7 V |
| Voltage - Output (Max) [Max] | 5.5 V |
| Voltage - Output (Min/Fixed) | 0.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.80 | |
| 10 | $ 3.41 | |||
| 25 | $ 3.23 | |||
| 100 | $ 2.80 | |||
| 250 | $ 2.65 | |||
| 500 | $ 2.38 | |||
| 1000 | $ 2.01 | |||
| 2500 | $ 1.91 | |||
| Digi-Reel® | 1 | $ 3.80 | ||
| 10 | $ 3.41 | |||
| 25 | $ 3.23 | |||
| 100 | $ 2.80 | |||
| 250 | $ 2.65 | |||
| 500 | $ 2.38 | |||
| 1000 | $ 2.01 | |||
| 2500 | $ 1.91 | |||
| Tape & Reel (TR) | 5000 | $ 1.84 | ||
Description
General part information
MPQ2166 Series
Buck Switching Regulator IC Positive Adjustable 0.6V 2 Output 2A/2A, 3A/1A 18-VFQFN
