109E1712M502

Active

Sanyo Denki America Inc.

FAN AXIAL 172X51MM 12VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsRotor Balancing Numbering System DC Fan

109E1712M502

Active

Sanyo Denki America Inc.

FAN AXIAL 172X51MM 12VDC WIRE

Deep-Dive with AI

DocumentsRotor Balancing Numbering System DC Fan

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	109E1712M502

Air Flow	4.14 mł/min
Air Flow	148 CFM
Approval Agency	CSA, TUV, UL
Bearing Type	Ball
Current Rating (Amps)	480 mA
Fan Type	Tubeaxial
Lifetime @ Temp.	40000 Hrs
Material - Blade	Plastic
Material - Frame	Aluminum
Noise	36 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Operating Temperature [Min]	-20 C
RPM	2000 RPM
Size / Dimension	Round
Size / Dimension [diameter]	172 mm
Static Pressure	0.271 in H2O
Static Pressure	67.6 Pa
Termination	2 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.8 VDC
Voltage Range [Min]	10.2 VDC
Weight	1.7 lbs
Weight	780 g
Width [y]	51 mm

109E1712 Series

Part	Features	Air Flow	Air Flow	Material - Blade	Static Pressure	Static Pressure	Termination	Fan Type	Power (Watts)	Approval Agency	Material - Frame	Weight	Weight	RPM	Voltage - Rated	Width [y]	Lifetime @ Temp.	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension	Size / Dimension [diameter]	Current Rating (Amps)	Voltage Range [Min]	Voltage Range [Max]	Bearing Type	Noise
Sanyo Denki America Inc. 109E1712Y501	Locked Rotor Protection Speed Sensor (Tach)	276 CFM	7.73 m³/min	Plastic	0.843 in H2O	210 Pa	3 Wire Leads	Tubeaxial	27.6 W	CSA TUV UL	Aluminum	1.7 lbs	780 g	3800 RPM	12 VDC	51 mm	40000 Hrs	60 °C	-20 °C	-20 C	60 °C	Round	172 mm	2.3 A	10.2 VDC	13.8 VDC	Ball	53 dB
Sanyo Denki America Inc. 109E1712H501	Locked Rotor Protection Speed Sensor (Tach)	226 CFM	6.33 m³/min	Plastic	0.551 in H2O	137.2 Pa	3 Wire Leads	Tubeaxial	14.4 W	CSA TUV UL	Aluminum	1.7 lbs	780 g		12 VDC	51 mm	40000 Hrs	70 °C	-20 °C	-20 C	70 °C	Round	172 mm	1.2 A	10.2 VDC	13.8 VDC	Ball	47 dB
Sanyo Denki America Inc. 109E1712F501	Locked Rotor Protection Speed Sensor (Tach)	180 CFM	5.04 mł/min	Plastic	0.382 in H2O	95.1 Pa	3 Wire Leads	Tubeaxial	10.8 W	CSA TUV UL	Aluminum	1.7 lbs	780 g	2500 RPM	12 VDC	51 mm	40000 Hrs	70 °C	-20 °C	-20 C	70 °C	Round	172 mm	0.68 A	10.2 VDC	13.8 VDC	Ball	42 dB
Sanyo Denki America Inc. 109E1712M501	Locked Rotor Protection Speed Sensor (Tach)	148 CFM	4.14 mł/min	Plastic	0.271 in H2O	67.6 Pa	3 Wire Leads	Tubeaxial		CSA TUV UL	Aluminum	1.7 lbs	780 g	2000 RPM	12 VDC	51 mm	40000 Hrs	70 °C	-20 °C	-20 C	70 °C	Round	172 mm	480 mA	10.2 VDC	13.8 VDC	Ball	36 dB
Sanyo Denki America Inc. 109E1712K501	Locked Rotor Protection Speed Sensor (Tach)	300 CFM	8.4 mł/min	Plastic	0.976 in H2O	243 Pa	3 Wire Leads	Tubeaxial	34.8 W	CSA TUV UL	Aluminum	1.7 lbs	780 g	4100 RPM	12 VDC	51 mm	40000 Hrs	60 °C	-20 °C	-20 C	60 °C	Round	172 mm	2.9 A	10.2 VDC	13.8 VDC	Ball	55 dB
Sanyo Denki America Inc. 109E1712M502		148 CFM	4.14 mł/min	Plastic	0.271 in H2O	67.6 Pa	2 Wire Leads	Tubeaxial		CSA TUV UL	Aluminum	1.7 lbs	780 g	2000 RPM	12 VDC	51 mm	40000 Hrs	70 °C	-20 °C	-20 C	70 °C	Round	172 mm	480 mA	10.2 VDC	13.8 VDC	Ball	36 dB
Sanyo Denki America Inc. 109E1712Y502		276 CFM	7.73 m³/min	Plastic	0.843 in H2O	210 Pa	2 Wire Leads	Tubeaxial	27.6 W	CSA TUV UL	Aluminum	1.7 lbs	780 g	3800 RPM	12 VDC	51 mm	40000 Hrs	60 °C	-20 °C	-20 C	60 °C	Round	172 mm	2.3 A	10.2 VDC	13.8 VDC	Ball	53 dB
Sanyo Denki America Inc. 109E1712K502		300 CFM	8.4 mł/min	Plastic	0.976 in H2O	243 Pa	2 Wire Leads	Tubeaxial	34.8 W	CSA TUV UL	Aluminum	1.7 lbs	780 g	4100 RPM	12 VDC	51 mm	40000 Hrs	60 °C	-20 °C	-20 C	60 °C	Round	172 mm	2.9 A	10.2 VDC	13.8 VDC	Ball	55 dB
