22-1/2X36YD

Active

3M (TC)

TAPE ELECTRICAL BLACK 1/2"X36YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE ELECTRICAL BLACK 1/2"X36YDS

Technical Specifications

Parameters and characteristics for this part

Specification	22-1/2X36YD

Adhesive	Rubber
Backing, Carrier	PVC (Poly Vinyl Chloride)
Color	Black
Length	36 yd
Length	32.9 m
Length	108 ft
Shelf Life	60 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature [Max]	80 °F, 27 °C
Storage/Refrigeration Temperature [Min]	10 °C
Tape Type	Electrical
Temperature Range	176 °F
Temperature Range	80 °C
Thickness	0.254 mm
Thickness	10 mils
Thickness	0.01 "
Usage	Electrically Insulating
Width	0.5 in
Width	12.7 mm
Width	0.5 in

Part	Width	Width	Width	Backing, Carrier	Storage/Refrigeration Temperature [Max]	Storage/Refrigeration Temperature [Min]	Color	Shelf Life Start	Temperature Range	Temperature Range	Length	Length	Length	Usage	Thickness	Thickness	Thickness	Tape Type	Adhesive	Shelf Life	Width
3M (TC) 22-1-1/2X36YD	1.5 "	38.1 mm	1 1/2	PVC (Poly Vinyl Chloride)	27 °C 80 °F	10 °C	Black	Date of Manufacture	176 °F	80 °C	36 yd	32.9 m	108 ft	Electrically Insulating	0.254 mm	10 mils	0.01 "	Electrical	Rubber	60 Months
3M (TC) 22-1/2X36YD	0.5 in	12.7 mm		PVC (Poly Vinyl Chloride)	27 °C 80 °F	10 °C	Black	Date of Manufacture	176 °F	80 °C	36 yd	32.9 m	108 ft	Electrically Insulating	0.254 mm	10 mils	0.01 "	Electrical	Rubber	60 Months	0.5 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Electrical Tape Rubber Adhesive Black 0.50" (12.70mm) 1/2" X 108' (32.9m) 36 yds
