222SMVABR

Active

Tusonix a Subsidiary of CTS Electronic Components

SWITCH TACTILE SPST-NO 0.05A 32V

Search across all available documentation for this part.

Active

Tusonix a Subsidiary of CTS Electronic Components

SWITCH TACTILE SPST-NO 0.05A 32V

Technical Specifications

Parameters and characteristics for this part

Specification	222SMVABR

Actuator Height off PCB, Vertical [z]	2.5 mm
Actuator Material	Silicone Rubber
Actuator Orientation	Top Actuated
Actuator Type	Standard
Circuit	SPST-NO
Contact Rating @ Voltage	0.05 A
Features	Tactile Feedback
Illumination	Non-Illuminated
Ingress Protection	IP57 - Dust Protected, Waterproof
Mechanical Life	100000 Cycles
Mounting Type	Surface Mount
Operating Force	300 gf
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Outline [x]	6 mm
Outline [y]	3.8 mm
Switch Function	Off-Mom
Switch Travel	0.35 mm
Termination Style	Gull Wing

Part	Contact Rating @ Voltage	Operating Force	Switch Travel	Illumination	Ingress Protection	Mounting Type	Features	Switch Function	Outline [x]	Outline [y]	Operating Temperature [Max]	Operating Temperature [Min]	Actuator Material	Actuator Type	Actuator Orientation	Actuator Height off PCB, Vertical [z]	Mechanical Life	Termination Style	Circuit
Tusonix a Subsidiary of CTS Electronic Components 222SMVABR	0.05 A	300 gf	0.35 mm	Non-Illuminated	IP57 - Dust Protected Waterproof	Surface Mount	Tactile Feedback	Off-Mom	6 mm	3.8 mm	85 °C	-40 °C	Silicone Rubber	Standard	Top Actuated	2.5 mm	100000 Cycles	Gull Wing	SPST-NO

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Tactile Switch SPST-NO Top Actuated Surface Mount
