ADN5-24-1PM-C

Active

ARTESYN / Advanced Energy

AC/DC DIN RAIL SUPPLY 24V 120W

Search across all available documentation for this part.

Active

ARTESYN / Advanced Energy

AC/DC DIN RAIL SUPPLY 24V 120W

Technical Specifications

Parameters and characteristics for this part

Specification	ADN5-24-1PM-C

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial), Industrial, Hazardous Locations
Approval Agency	UL, CE, cULus
Current - Output (Max) [Max]	5 A
DC Voltage - Input (Max) [Max]	375 V
DC Voltage - Input (Min) [Min]	90 V
Efficiency	90 %
Features	PFC, Universal Input, Load Sharing, Adjustable Output, IP20
Input Type	AC or DC
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Size / Dimension [x]	4.37 in
Size / Dimension [x]	111 mm
Size / Dimension [y]	1.97 "
Size / Dimension [y]	50 mm
Size / Dimension [z]	123 mm
Size / Dimension [z]	4.85 in
Standard Number	508, Class I Div 2, 60950-1
Voltage - Output 1	24 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Input Type	Approval Agency	Number of Outputs	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	DC Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Voltage - Output 1	Efficiency	Applications	DC Voltage - Input (Min) [Min]	Features	Standard Number	AC Voltage - Input [Min]	AC Voltage - Input [Max]
ARTESYN / Advanced Energy ADN5-24-3PM-C	-25 °C	70 °C	AC or DC	CE	1	1.97 "	4.85 "	50 mm	123 mm	111 mm	4.36 in	760 V	5 A	24 V	85 %	Hazardous Locations Industrial ITE (Commercial)	450 V	Adjustable Output IP20 Load Sharing PFC
ARTESYN / Advanced Energy ADN5-24-1PM-C	-25 °C	70 °C	AC or DC	CE cULus UL	1	1.97 "	4.37 in	50 mm	111 mm	123 mm	4.85 in	375 V	5 A	24 V	90 %	Hazardous Locations Industrial ITE (Commercial)	90 V	Adjustable Output IP20 Load Sharing PFC Universal Input	508 60950-1 Class I Div 2	85 VAC	264 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 24V 120W
