HD48-3-A+G

Active

SL POWER / Advanced Energy

AC/DC CONVERTER 48V 144W

Search across all available documentation for this part.

Active

SL POWER / Advanced Energy

AC/DC CONVERTER 48V 144W

Technical Specifications

Parameters and characteristics for this part

Specification	HD48-3-A+G

Applications	ITE (Commercial)
Approval Agency	cURus, CE, TUV
Current - Output 1	4 A
Features	Remote Sense, Universal Input, Adjustable Output
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Power (Watts)	144 W
Size / Dimension [x]	9 in
Size / Dimension [x]	228.6 mm
Size / Dimension [y]	4.88 in
Size / Dimension [y]	124 mm
Size / Dimension [z]	2.75 in
Size / Dimension [z]	69.9 mm
Type	Linear
Voltage - Input [Max]	240 VAC
Voltage - Input [Min]	100 VAC
Voltage - Output 1	48 V

Part	Number of Outputs	Mounting Type	Power (Watts)	Current - Output 1	Features	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Voltage - Input [Max]	Voltage - Input [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Applications	Type
SL POWER / Advanced Energy HD48-3-A+G	1	Chassis Mount	144 W	4 A	Adjustable Output Remote Sense Universal Input	48 V	70 °C	0 °C	CE cURus TUV	240 VAC	100 VAC	2.75 in	9 in	69.9 mm	4.88 in	124 mm	228.6 mm	ITE (Commercial)	Linear

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 144.14

General part information

Linear AC DC Converters 1 Output 48V 100 ~ 240 VAC Input
