PEG127KC3270QL1

Unknown

KEMET

CAP ALUM 270UF 40V AXIAL TH

Search across all available documentation for this part.

Unknown

KEMET

CAP ALUM 270UF 40V AXIAL TH

Technical Specifications

Parameters and characteristics for this part

Specification	PEG127KC3270QL1

Applications	Automotive
Capacitance	270 µF
Height - Seated (Max) [Max] [z]	20 mm
Height - Seated (Max) [Max] [z]	0.787 "
Lifetime @ Temp.	5000 Hrs
Mounting Type	Through Hole
Package / Case	Can, Axial
Polarization	Polar
Ripple Current @ High Frequency	3.7 A
Ripple Current @ Low Frequency	1.295 A
Size / Dimension [diameter]	0.512 in
Size / Dimension [diameter]	13 mm
Tolerance [Max]	30 %
Tolerance [Min]	-10 %
Voltage - Rated	40 V

Part	Ratings	Ripple Current @ High Frequency	Polarization	Size / Dimension [diameter]	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [x]	Applications	Ripple Current @ Low Frequency	Tolerance [Min]	Tolerance [Max]	Capacitance	ESR (Equivalent Series Resistance)	Lifetime @ Temp.	Mounting Type	Voltage - Rated	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET PEG127KA3110QT1	AEC-Q200	2.3 A	Polar	0.394 in	10 mm	0.787 in	20 mm	Automotive	805 mA	-10 %	30 %	110 µF	710 mOhm	1600 Hrs	Through Hole	40 V	Axial Can
KEMET PEG127KC3270QL1		3.7 A	Polar	0.512 in	13 mm			Automotive	1.295 A	-10 %	30 %	270 µF		5000 Hrs	Through Hole	40 V	Axial Can	20 mm	0.787 "
KEMET PEG127KB3220QT1	AEC-Q200		Polar	0.394 in	10 mm	1.142 inches	29 mm	Automotive	1.19 A	-10 %	30 %	220 µF	360 mOhm	1600 Hrs	Through Hole	40 V	Axial Can

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

270 µF 40 V Aluminum Electrolytic Capacitors Axial, Can 301mOhm @ 100Hz 5000 Hrs @ 105°C
