AM6T-2415SZ

Active

aimtec

DC DC CONVERTER 15V 6W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM6T-2415SZ

Active

aimtec

DC DC CONVERTER 15V 6W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AM6T-2415SZ

Applications	ITE (Commercial)
Approval Agency	CE
Current - Output (Max) [Max]	400 mA
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	24-DIP Module, 7 Leads
Power (Watts)	6 W
Size / Dimension [x]	31.8 mm
Size / Dimension [x]	1.25 "
Size / Dimension [y]	0.8 in
Size / Dimension [y]	20.3 mm
Size / Dimension [z]	0.4 "
Size / Dimension [z]	10.2 mm
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	15 V

AM6T Series

Part	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Power (Watts)	Current - Output (Max)	Current - Output (Max)	Approval Agency	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Voltage - Output 2	Package / Case	Number of Outputs	Type	Voltage - Output 1	Voltage - Input (Max) [Max]	Mounting Type	Efficiency	Standard Number	Voltage - Isolation	Voltage - Input (Min) [Min]	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Size / Dimension [y]	Size / Dimension [z]	Current - Output (Max)	Current - Output (Max) [Max]
aimtec AM6T-2412DH35Z	85 °C	-40 °C	ITE (Commercial)	6 W	250 mA	250 mA	CE IEC UL	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	-12 V	24-DIP Module 8 Leads	2	Isolated Module	12 V	36 V	Through Hole	80 %	62368-1	3.5 kV	18 V
aimtec AM6T-4824D-NZ	85 °C	-40 °C	ITE (Commercial)	6 W	125 mA		CE	10.16 mm	31.8 mm	10.2 mm		20.3 mm		-24 V	24-DIP Module	2	Isolated Module		75 V	Through Hole	85 %		1.5 kV	36 V	-24 V	24 V	20.32 mm	1.25 "	125 mA
aimtec AM6T-1205D-NZ	85 °C	-40 °C	ITE (Commercial)	6 W			CE							-5 V	24-DIP Module	2	Isolated Module		18 V	Through Hole	80 %		1.5 kV	9 V	-5 V	5 V				600 mA
aimtec AM6T-2415D-NZ	85 °C	-40 °C	ITE (Commercial)	6 W			CE							-15 V	24-DIP Module 8 Leads	2	Isolated Module		36 V	Through Hole	87 %		1.5 kV	18 V	-15 V	15 V
aimtec AM6T-4805SZ	85 °C	-40 °C	ITE (Commercial)	6 W			CE	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm		24-DIP Module	1	Isolated Module	5 V	72 V	Through Hole	80 %		1.5 kV	36 V						1.2 A
aimtec AM6T-1218DZ	85 °C	-40 °C	ITE (Commercial)	6 W	166 mA		CE	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	-18 V	24-DIP Module 8 Leads	2	Isolated Module	18 V	18 V	Through Hole	80 %		1.5 kV	9 V					166 mA
aimtec AM6T-2415SZ	85 °C	-40 °C	ITE (Commercial)	6 W			CE	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm		24-DIP Module 7 Leads	1	Isolated Module	15 V	36 V	Through Hole			1.5 kV	18 V						400 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 17.37
		5	$ 17.02
		10	$ 16.68
		20	$ 16.35
		40	$ 16.02
		60	$ 15.70
		80	$ 15.39

Description

General part information

AM6T Series

Isolated Module DC DC Converter 1 Output 15V 400mA 18V - 36V Input
