REM10-2415S/A/CTRL

Active

RECOM Power

ISOLATED DC/DC CONVERTERS - THROUGH HOLE 10W 18-36VIN 15VOUT DIP24

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Datasheet

REM10-2415S/A/CTRL

Active

RECOM Power

ISOLATED DC/DC CONVERTERS - THROUGH HOLE 10W 18-36VIN 15VOUT DIP24

Deep-Dive with AI

DocumentsDatasheet Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	REM10-2415S/A/CTRL

Applications	ITE (Commercial), Medical
Control Features	Active Low, Enable
Current - Output (Max) [Max]	670 mA
Efficiency	89 %
Features	OVP, UVLO, OCP, Remote On/Off, SCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Package / Case	24-DIP Module, 6 Leads
Power (Watts)	10 W
Size / Dimension [x]	31.8 mm
Size / Dimension [x]	1.25 "
Size / Dimension [y]	0.8 in
Size / Dimension [y]	20.3 mm
Size / Dimension [z]	0.4 "
Size / Dimension [z]	10.2 mm
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	5000 V
Voltage - Output 1	15 V

REM10-S_D(W) Series

Isolated DC/DC Converters - Through Hole 10W 18-75Vin 15Vout DIP24

Part	Power (Watts)	Applications	Voltage - Isolation	Features	Voltage - Input (Max) [Max]	Voltage - Output 1	Control Features	Efficiency	Voltage - Input (Min) [Min]	Type	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Number of Outputs	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)	Mounting Type	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Current - Output (Max) [Max]
RECOM Power REM10-2405DW/C	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	36 V	5 V	Active Low Enable	89 %	9 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 6 Leads	2	-5 V	1 A	1 A	Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm
RECOM Power REM10-4812SW/A/CTRL	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	75 V	12 V	Active Low Enable	89 %	18 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 6 Leads	1				Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	830 mA
RECOM Power REM10-4805DW/C	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	75 V	5 V	Active Low Enable	88 %	18 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 6 Leads	2	-5 V	1 A	1 A	Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm
RECOM Power REM10-2415S/A/CTRL	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	36 V	15 V	Active Low Enable	89 %	18 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 6 Leads	1				Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	670 mA
RECOM Power REM10-4812S/C	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	75 V	12 V	Active Low Enable	89 %	36 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 5 Leads	1				Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	830 mA
RECOM Power REM10-4812SW/A	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	75 V	12 V	Active Low Enable	89 %	18 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 5 Leads	1				Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	830 mA
RECOM Power REM10-1205D/A/CTRL	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	18 V	5 V	Active Low Enable	84 %	9 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 7 Leads	2	-5 V	1 A	1 A	Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm
RECOM Power REM10-1205S/C	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	18 V	5 V	Active Low Enable	85.5 %	9 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 5 Leads	1				Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	2 A
RECOM Power REM10-0505D/C	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	9 V	5 V	Active Low Enable	83 %	4.5 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 6 Leads	2	-5 V	1 A	1 A	Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm
RECOM Power REM10-0515D/A	10 W	ITE (Commercial) Medical	5000 V	OCP OVP Remote On/Off SCP UVLO	9 V	15 V	Active Low Enable	86.5 %	4.5 V	Isolated Module	-40 °C	105 ░C	24-DIP Module 6 Leads	2	-15 V	333 mA	333 mA	Through Hole	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	7	$ 85.73
Sager	N/A	1	$ 89.72
		5	$ 84.11
		10	$ 79.17
		25	$ 73.74
		50	$ 70.83
		100	$ 69.02
		250	$ 65.65

Description

General part information

REM10-S_D(W) Series

Isolated DC/DC Converters - Through Hole 10W 18-75Vin 15Vout DIP24
