VSM5AN6CV20
ObsoleteBANNER ENGINEERING
VSM SERIES: 5 MM THREADED BARREL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
VSM5AN6CV20
ObsoleteBANNER ENGINEERING
VSM SERIES: 5 MM THREADED BARREL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | VSM5AN6CV20 |
|---|---|
| Cable Length | 78.74 in |
| Cable Length | 2 m |
| Connection Method | Cable |
| Ingress Protection | IP67 |
| Light Source | Infrared |
| Output Configuration | NPN - Light-ON |
| Response Time | 2.5 ms |
| Sensing Distance | 0.787 in |
| Sensing Distance | 20 mm |
| Sensing Method | Diffuse |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
VSM5AN6 Series
Diffuse Optical Sensor 0.787" (20mm) NPN - Light-ON
Documents
Technical documentation and resources
