TBC-240-A-C-A
ActiveATC-Diversified Electronics
RELAY TIME DEL 10230SEC 10A 250V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TBC-240-A-C-A |
|---|---|
| Contact Rating @ Voltage | 10 A |
| Delay Time [Max] | 10230 Sec |
| Delay Time [Min] | 10 Sec |
| Function | On-Delay |
| Mounting Type | Socketable |
| Relay Type | Mechanical Relay |
| Termination Style | Plug In, 8 Pin (Octal) |
| Timing Adjustment Method | DIP Switches |
| Timing Initiate Method | Input Voltage |
| Voltage - Supply | 24 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 253.31 | |
Description
General part information
TBC-240 Series
On-Delay Time Delay Relay 10 Sec ~ 10230 Sec Delay 10A @ 250VAC/24VDC Socketable
