T 3644 005

Active

Amphenol Tuchel Industrial

CONN PLUG MALE 14P SOLDER CUP

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN PLUG MALE 14P SOLDER CUP

Technical Specifications

Parameters and characteristics for this part

Specification	T 3644 005

Color	Silver
Connector Type	Plug, Male Pins
Contact Finish - Mating	Silver
Current Rating (Amps)	3 A
Fastening Type	Bayonet Lock
Features	Strain Relief
Ingress Protection	IP40
Mounting Type	Free Hanging (In-Line), Right Angle
Number of Positions	14
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Die Cast
Shell Size - Insert	M16-14
Voltage Rating	60 VDC

Part	Connector Type	Contact Finish - Mating	Mounting Type	Color	Current Rating (Amps)	Fastening Type	Shell Material	Shell Finish	Ingress Protection	Primary Material	Voltage Rating	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions	Orientation	Features	Shell Size - Insert
Amphenol Tuchel Industrial T 3644 502	Male Pins Plug	Silver	Free Hanging (In-Line)	Silver	3 A	Bayonet Lock	Die Cast	Nickel	IP40	Metal	60 VDC	100 °C	-40 °C	14	Keyed	Cable Clamp Strain Relief	M16-14
Amphenol Tuchel Industrial T 3644 005	Male Pins Plug	Silver	Free Hanging (In-Line) Right Angle	Silver	3 A	Bayonet Lock	Die Cast	Nickel	IP40	Metal	60 VDC	100 °C	-40 °C	14	Keyed	Strain Relief	M16-14

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 16.68

General part information

14 Position Circular Connector Plug, Male Pins Solder Cup
