9BFB12P2H003
ActiveSanyo Denki America Inc.
FAN BLOWER 120X32MM 12VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsNumber System Blower
9BFB12P2H003
ActiveSanyo Denki America Inc.
FAN BLOWER 120X32MM 12VDC WIRE
Deep-Dive with AI
DocumentsNumber System Blower
Technical Specifications
Parameters and characteristics for this part
| Specification | 9BFB12P2H003 |
|---|---|
| Air Flow | 1.58 m³/min |
| Air Flow | 56.5 CFM |
| Approval Agency | cURus, TUV |
| Bearing Type | Ball |
| Current Rating (Amps) | 2.3 A |
| Fan Type | Blower |
| Features | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Lifetime @ Temp. | 40000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 62 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 27.6 W |
| RPM | 3750 RPM |
| Size / Dimension | Square/Rounded |
| Size / Dimension [x] | 120 mm |
| Size / Dimension [z] | 120 mm |
| Static Pressure | 1250 Pa |
| Static Pressure | 5.02 in H2O |
| Termination | 4 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.2 VDC |
| Voltage Range [Min] | 10.8 VDC |
| Weight | 340.19 g |
| Weight | 0.75 lb |
| Width [y] | 32 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 48.72 | |
| 20 | $ 41.96 | |||
| 40 | $ 40.53 | |||
| 60 | $ 39.72 | |||
| 100 | $ 38.72 | |||
| 260 | $ 36.91 | |||
Description
General part information
9BFB12 Series
Fan Blower 12VDC Square/Rounded - 120mm L x 120mm H Ball 56.5 CFM (1.58m³/min) 4 Wire Leads
