PX0742/P/75OHM
ObsoleteBULGIN LIMITED
RF BNC CONNECTOR, MALE, PANEL MOUNT, CABLE MOUNT, CRIMP TERMINAL, PLUG, ROHS COMPLIANT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PX0742/P/75OHM
ObsoleteBULGIN LIMITED
RF BNC CONNECTOR, MALE, PANEL MOUNT, CABLE MOUNT, CRIMP TERMINAL, PLUG, ROHS COMPLIANT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PX0742/P/75OHM |
|---|---|
| Body Finish | Nickel |
| Body Material | Brass |
| Center Contact Material | Brass |
| Center Contact Plating | Silver |
| Connector Style | BNC |
| Connector Type | Male Pin, Plug |
| Contact Termination | Crimp |
| Fastening Type | Bayonet Lock |
| Housing Color | Black |
| Impedance | 75 Ohms |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Mounting Type | Free Hanging (In-Line) |
| Number of Ports | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Shield Termination | Crimp |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
PX0742 Series
BNC Connector Plug, Male Pin 75 Ohms Free Hanging (In-Line) Crimp
