TPK-10A
ActiveOptiFuse
UL CLASS M FUSE, TIME DELAY 10A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TPK-10A
ActiveOptiFuse
UL CLASS M FUSE, TIME DELAY 10A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TPK-10A |
|---|---|
| Applications | Electrical, Industrial |
| Approval Agency | UL 248, cULus |
| Class | M |
| Current Rating (Amps) | 10 A |
| Fuse Type | Cartridge |
| Mounting Type | Requires Holder |
| Package / Case | 5AG |
| Package / Case [x] | 10 mm |
| Package / Case [y] | 38 mm |
| Response Time | Slow Blow |
| Size / Dimension [diameter] | 0.406 in |
| Size / Dimension [diameter] | 10.3 mm |
| Size / Dimension [x] | 38 mm |
| Size / Dimension [x] | 1.496 " |
| Voltage Rating - AC | 500 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 12.99 | |
| 10 | $ 12.67 | |||
| 25 | $ 12.29 | |||
| 50 | $ 10.36 | |||
| 100 | $ 8.50 | |||
| 250 | $ 7.69 | |||
| 500 | $ 6.43 | |||
| 1000 | $ 5.61 | |||
Description
General part information
TPK Series
10A 500 VAC Fuse Cartridge Requires Holder
