3314H-1-254

Active

Bourns Inc.

TRIMMER 250KOHM 0.25W PC PIN TOP

Search across all available documentation for this part.

Active

Bourns Inc.

TRIMMER 250KOHM 0.25W PC PIN TOP

Technical Specifications

Parameters and characteristics for this part

Part	Number of Turns	Mounting Type	Adjustment Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Power (Watts)	Power (Watts)	Temperature Coefficient	Termination Style	Resistive Material	Resistance	Tolerance
Bourns Inc. 3314H-2-103	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	10000 Ohms	20 %
Bourns Inc. 3314H-1-500	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	50 Ohms	20 %
Bourns Inc. 3314H-1-100	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	10 Ohms	20 %
Bourns Inc. 3314H-1-205	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	2 MOhms	20 %
Bourns Inc. 3314H-2-205	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	2 MOhms	20 %
Bourns Inc. 3314H-1-101	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	100 Ohms	20 %
Bourns Inc. 3314H-1-200	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	20 Ohms	20 %
Bourns Inc. 3314H-1-254	1	Through Hole	Top Adjustment	4.5 mm	0.177 in	0.177 "	4.5 mm	0.25 W	250 mW	100 ppm/°C	PC Pins	Cermet	250 kOhms	20 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	200	$ 1.60

General part information

250 kOhms 0.25W, 1/4W PC Pins Through Hole Trimmer Potentiometer Cermet 1.0 Turn Top Adjustment
