H7WWH-1506G
ActiveAssmann WSW Components
CABLE D-SUB-HFU15H/AE15G/HFU15H
Deep-Dive with AI
Search across all available documentation for this part.
H7WWH-1506G
ActiveAssmann WSW Components
CABLE D-SUB-HFU15H/AE15G/HFU15H
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | H7WWH-1506G |
|---|---|
| 1st Connector | Receptacle, Female Sockets |
| 2nd Connector | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Contact Finish Thickness | 10 Áin |
| Contact Finish Thickness | 0.25 Ám |
| Length | 6 ft |
| Length | 1.83 m |
| Number of Positions | 15 |
| Shielding | Unshielded |
| Type | DB15 |
| Usage | Patch |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 7.28 | |
| 10 | $ 6.59 | |||
| 25 | $ 6.22 | |||
| 50 | $ 6.07 | |||
| 100 | $ 5.77 | |||
| 250 | $ 5.16 | |||
| 500 | $ 4.86 | |||
| 1000 | $ 4.25 | |||
Description
General part information
H7WWH-15 Series
D-Sub Cable Assembly DB15 Gray, Ribbon 6.00' (1.83m) Receptacle, Female Sockets to Receptacle, Female Sockets Unshielded
Documents
Technical documentation and resources
No documents available
