LFXP2-8E-5QN208C

Active

LATTICE SEMICONDUCTOR

IC FPGA 146 I/O 208QFP

Search across all available documentation for this part.

Active

LATTICE SEMICONDUCTOR

IC FPGA 146 I/O 208QFP

Technical Specifications

Parameters and characteristics for this part

Specification	LFXP2-8E-5QN208C

Mounting Type	Surface Mount
Number of I/O	146
Number of LABs/CLBs	1000
Number of Logic Elements/Cells	8000
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	0 °C
Package / Case	208-BFQFP
Supplier Device Package	208-PQFP (28x28)
Total RAM Bits	226304

Part	Mounting Type	Number of LABs/CLBs	Number of Logic Elements/Cells	Total RAM Bits	Supplier Device Package	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Number of I/O
LATTICE SEMICONDUCTOR LFXP2-8E-7FT256C	Surface Mount	1000	8000	226304	256-FTBGA (17x17)	256-LBGA	0 °C	85 °C	201
LATTICE SEMICONDUCTOR LFXP2-8E-5FT256I	Surface Mount	1000	8000	226304	256-FTBGA (17x17)	256-LBGA	-40 C	100 °C	201
LATTICE SEMICONDUCTOR LFXP2-8E-6FT256C	Surface Mount	1000	8000	226304	256-FTBGA (17x17)	256-LBGA	0 °C	85 °C	201
LATTICE SEMICONDUCTOR LFXP2-8E-5TN144I	Surface Mount	1000	8000	226304	144-TQFP (20x20)	144-LQFP	-40 C	100 °C	100 I/O
LATTICE SEMICONDUCTOR LFXP2-8E-5FTN256I	Surface Mount	1000	8000	226304	256-FTBGA (17x17)	256-LBGA	-40 C	100 °C	201
LATTICE SEMICONDUCTOR LFXP2-8E-5QN208C	Surface Mount	1000	8000	226304	208-PQFP (28x28)	208-BFQFP	0 °C	85 °C	146
LATTICE SEMICONDUCTOR LFXP2-8E-7M132C	Surface Mount	1000	8000	226304	132-CSBGA (8x8)	132-LFBGA CSPBGA	0 °C	85 °C	86
LATTICE SEMICONDUCTOR LFXP2-8E-5MN132I	Surface Mount	1000	8000	226304	132-CSBGA (8x8)	132-LFBGA CSPBGA	-40 C	100 °C	86
LATTICE SEMICONDUCTOR LFXP2-8E-5QN208I	Surface Mount	1000	8000	226304	208-PQFP (28x28)	208-BFQFP	-40 C	100 °C	146

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

XP2 Field Programmable Gate Array (FPGA) IC 146 226304 8000 208-BFQFP
