09380423001

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, HAN COM SERIES, INSERT, 6 CONTACTS, 16B, PLUG

Search across all available documentation for this part.

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, HAN COM SERIES, INSERT, 6 CONTACTS, 16B, PLUG

Technical Specifications

Parameters and characteristics for this part

Specification	09380423001

Color	Gray
Connector Type	Insert without Contacts
Contact Type	Han® D, Han® C
Gender	Male
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions	Ground
Number of Positions	6, 36
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	16 B
Termination Style	Crimp

Part	Contact Type	Size	Number of Positions	Number of Positions	Connector Type	Gender	Operating Temperature [Max]	Operating Temperature [Min]	Material Flammability Rating	Housing Material	Termination Style	Color
HARTING Technology Group 09380423001	Han® C Han® D	16 B	Ground	6 36	Insert without Contacts	Male	125 °C	-40 °C	UL94 V-0	Polycarbonate (PC)	Crimp	Gray
HARTING Technology Group 09380423104			Ground	6 36	Insert without Contacts	Female					Crimp

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Male Insert without Contacts Gray 6+36+Ground Position Crimp
