Technical Specifications
Parameters and characteristics for this part
| Specification | RA2A48D40M |
|---|---|
| Approval Agency | EAC, CE, cURus, CSA |
| Circuit | SPST-NO (1 Form A) x 2 |
| Load Current | 40 A |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Output Type | AC, Zero Cross |
| Package / Case | Hockey Puck |
| Termination Style | Quick Connect - 0.250" (6.3mm) |
| Voltage - Input [Max] | 32 V |
| Voltage - Input [Min] | 4.5 V |
| Voltage - Load [Max] | 530 V |
| Voltage - Load [Min] | 42 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 120.00 | |
| 10 | $ 114.00 | |||
| 50 | $ 108.00 | |||
Description
General part information
RA2A48 Series
Solid State SPST-NO (1 Form A) x 2 Hockey Puck
