GD25LQ256DWIGR
GigaDevice Semiconductor (HK) Limited
IC FLASH 256MBIT SPI/QUAD 8WSON
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
GD25LQ256DWIGR
GigaDevice Semiconductor (HK) Limited
IC FLASH 256MBIT SPI/QUAD 8WSON
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | GD25LQ256DWIGR |
|---|---|
| Clock Frequency | 120 MHz |
| Memory Format | FLASH |
| Memory Interface | SPI - Quad I/O |
| Memory Organization | 32 M |
| Memory Size | 256 Gbit |
| Memory Type | Non-Volatile |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 8-WDFN Exposed Pad |
| Supplier Device Package | 8-WSON (5x6) |
| Technology | FLASH - NOR |
| Voltage - Supply [Max] | 2 V |
| Voltage - Supply [Min] | 1.65 V |
| Write Cycle Time - Word, Page | 2.4 ms |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.85 | |
| 10 | $ 3.42 | |||
| 25 | $ 3.26 | |||
| 50 | $ 3.15 | |||
| 100 | $ 3.04 | |||
| 250 | $ 2.90 | |||
| 500 | $ 2.79 | |||
| 1000 | $ 2.70 | |||
| Digi-Reel® | 1 | $ 3.85 | ||
| 10 | $ 3.42 | |||
| 25 | $ 3.26 | |||
| 50 | $ 3.15 | |||
| 100 | $ 3.04 | |||
| 250 | $ 2.90 | |||
| 500 | $ 2.79 | |||
| 1000 | $ 2.70 | |||
| Tape & Reel (TR) | 3000 | $ 2.55 | ||
Description
General part information
GD25LQ256 Series
FLASH - NOR Memory IC 256Mbit SPI - Quad I/O 120 MHz 8-WSON (5x6)
Documents
Technical documentation and resources
