MSAP-05PFFR-SF8002

Active

Amphenol LTW

CONN M12 FEM RA 5PIN PLAST M16.0

Search across all available documentation for this part.

Active

Amphenol LTW

CONN M12 FEM RA 5PIN PLAST M16.0

Technical Specifications

Parameters and characteristics for this part

Specification	MSAP-05PFFR-SF8002

Color	Black
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	4 A
Features	Board Guide, Board Lock
Ingress Protection	IP68 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Right Angle, Panel Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	M12-5
Shielding	Unshielded
Termination	Solder
Voltage Rating	60 VDC

Part	Shell Material	Shielding	Contact Material	Connector Type	Mounting Feature	Contact Finish - Mating	Primary Material	Current Rating (Amps)	Termination	Voltage Rating	Features	Ingress Protection	Color	Mounting Type	Shell Size - Insert	Operating Temperature [Min]	Operating Temperature [Max]	Insert Material	Orientation
Amphenol LTW MSAP-05PFFR-SF8002	Glass Filled Nylon Polyamide (PA)	Unshielded	Copper Alloy	Female Sockets Plug	Bulkhead - Front Side Nut	Gold	Plastic	4 A	Solder	60 VDC	Board Guide Board Lock	IP68 - Dust Tight Waterproof	Black	Panel Mount Right Angle Through Hole	M12-5	-40 °C	105 ░C	Polyamide (PA) Nylon Glass Filled	A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Position Circular Connector Plug, Female Sockets Solder
