5120.1311.1

Active

SCHURTER Inc.

PWR ENT RCPT IEC320-C18 PNL SLDR

Search across all available documentation for this part.

Active

SCHURTER Inc.

PWR ENT RCPT IEC320-C18 PNL SLDR

Technical Specifications

Parameters and characteristics for this part

Specification	5120.1311.1

Accomodates a Fuse	False
Approval Agency	CCC, ENEC, cULus
Connector Style	IEC 320-C18
Connector Type	Male Blades, Receptacle
Current Rating - Appliance Inlet	2 A
Current Rating - Filter	2 A
Features	Shielded
Filter Type	Filtered (EMI, RFI) - Commercial, Medical
Ingress Protection	IP40
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Flange
Number of Positions	2
Panel Cutout Dimensions	Variable Size
Termination	Solder Eyelet
Voltage Rating - Appliance Inlet	250 VAC

Part	Voltage Rating - Appliance Inlet	Termination	Approval Agency	Ingress Protection	Mounting Type	Features	Current Rating - Filter	Material Flammability Rating	Accomodates a Fuse	Number of Positions	Filter Type	Panel Cutout Dimensions	Connector Style	Current Rating - Appliance Inlet	Connector Type
SCHURTER Inc. 5120.1311.1	250 VAC	Solder Eyelet	CCC cULus ENEC	IP40	Flange Panel Mount	Shielded	2 A	UL94 V-0		2	Filtered (EMI RFI) - Commercial Medical	Variable Size	IEC 320-C18	2 A	Male Blades Receptacle

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Power Entry Connector Receptacle, Male Blades IEC 320-C18 Panel Mount, Flange
