BD2069FJ-MGE2

Active

Rohm Semiconductor

2.4A CURRENT LIMIT HIGH SIDE SWITCH ICS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsBD2069FJ-MGE2 Flammability AEC-Q101 Automotive Requirements +20

BD2069FJ-MGE2

Active

Rohm Semiconductor

2.4A CURRENT LIMIT HIGH SIDE SWITCH ICS

Deep-Dive with AI

DocumentsBD2069FJ-MGE2 Flammability AEC-Q101 Automotive Requirements +20

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	BD2069FJ-MGE2

Current - Output (Max) [Max]	3 A
Fault Protection	UVLO, Current Limiting (Fixed), Over Temperature, Reverse Current
Grade	Automotive
Input Type	Non-Inverting
Interface	On/Off
Mounting Type	Surface Mount
Number of Outputs	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Output Configuration	High Side
Output Type	N-Channel
Package / Case	8-SOIC
Package / Case [x]	0.154 in
Package / Case [y]	3.9 mm
Qualification	AEC-Q100
Ratio - Input:Output [custom]	1:2
Rds On (Typ)	80 mOhm
Supplier Device Package	8-SOP-J
Switch Type	USB Switch
Voltage - Load [Max]	5.5 V
Voltage - Load [Min]	2.7 V
Voltage - Supply (Vcc/Vdd)	False

BD2069FJ-M Series

2.4A Current Limit High Side Switch ICs

Part	Rds On (Typ)	Package / Case	Package / Case [y]	Package / Case [x]	Voltage - Load [Max]	Voltage - Load [Min]	Input Type	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Output Configuration	Number of Outputs	Voltage - Supply (Vcc/Vdd)	Switch Type	Interface	Fault Protection	Supplier Device Package	Ratio - Input:Output [custom]	Qualification	Grade	Current - Output (Max) [Max]
Rohm Semiconductor BD2069FJ-MGE2	80 mOhm	8-SOIC	3.9 mm	0.154 in	5.5 V	2.7 V	Non-Inverting	N-Channel	85 °C	-40 °C	Surface Mount	High Side	2		USB Switch	On/Off	Current Limiting (Fixed) Over Temperature Reverse Current UVLO	8-SOP-J	1:2	AEC-Q100	Automotive	3 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 2.72
		10	$ 1.76
		25	$ 1.50
		100	$ 1.22
		250	$ 1.08
		500	$ 1.00
		1000	$ 0.93
	Digi-Reel®	1	$ 2.72
		10	$ 1.76
		25	$ 1.50
		100	$ 1.22
		250	$ 1.08
		500	$ 1.00
		1000	$ 0.93
	Tape & Reel (TR)	2500	$ 0.85
		5000	$ 0.81
		7500	$ 0.78
		12500	$ 0.76
Newark	Each (Supplied on Cut Tape)	1	$ 2.79
		10	$ 1.50
		25	$ 1.40
		50	$ 1.30
		100	$ 1.21
		300	$ 1.06
		500	$ 0.96
		1000	$ 0.88

Description

General part information

BD2069FJ-M Series

BD2069FJ-M is dual channel high side switch ICs with an over-current protection for of Universal Serial Bus (USB) power supply line. Its switch unit has two channels of N-Channel power MOSFET. Over current detection circuit, thermal shutdown circuit, under-voltage lockout, and soft-start circuit are built in.
