PSR53-9G

Active

EOS Power India Private Ltd

MODULE DC-DC 40VIN 1-OUT 5V 3A 15W 6-PIN

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

MODULE DC-DC 40VIN 1-OUT 5V 3A 15W 6-PIN

Technical Specifications

Parameters and characteristics for this part

Specification	PSR53-9G

Applications	Railway, ITE (Commercial)
Current - Output (Max) [Max]	3 A
Efficiency	87 %
Features	UVLO, Remote On/Off, SCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	71 °C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Type	Non-Isolated PoL Module, Conformal Coated
Voltage - Input (Max) [Max]	80 V
Voltage - Input (Min) [Min]	8 V
Voltage - Output 1	5 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max) [Max]	Package / Case	Features	Efficiency	Applications	Mounting Type	Voltage - Output 1	Number of Outputs	Type	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Control Features
EOS Power India Private Ltd PSR53-9G	-40 °C	71 °C	3 A	Module	Remote On/Off SCP UVLO	87 %	ITE (Commercial) Railway	Through Hole	5 V	1	Conformal Coated Non-Isolated PoL Module	80 V	8 V
EOS Power India Private Ltd PSR53-7IP	-25 °C	71 °C	3 A	6-DIP Module	OCP Remote On/Off SCP UVLO	79 %	ITE (Commercial) Railway	Through Hole	5 V	1	Conformal Coated Non-Isolated PoL Module	80 V	8 V	Active Low Enable

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Non-Isolated PoL Module, Conformal Coated DC DC Converter 1 Output 5V 3A 8V - 80V Input
