AK1301-9RG
ActiveEOS Power India Private Ltd
MODULE DC-DC 15VIN 1-OUT 12V 10A 150W 15-PIN
Deep-Dive with AI
Search across all available documentation for this part.
AK1301-9RG
ActiveEOS Power India Private Ltd
MODULE DC-DC 15VIN 1-OUT 12V 10A 150W 15-PIN
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AK1301-9RG |
|---|---|
| Applications | Railway, ITE (Commercial) |
| Approval Agency | cCSAus, NEMKO, CE, cURus, TUV |
| Current - Output (Max) [Max] | 10 A |
| Efficiency | 80 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -40 °C |
| Size / Dimension [x] | 167.6 mm |
| Size / Dimension [x] | 6.6 " |
| Size / Dimension [y] | 111.8 mm |
| Size / Dimension [y] | 4.4 " |
| Size / Dimension [z] | 81.3 mm |
| Size / Dimension [z] | 3.2 in |
| Type | Conformal Coated, Enclosed |
| Voltage - Input (Max) [Max] [custom] | 35 V |
| Voltage - Input (Min) [Min] | 8 V |
| Voltage - Isolation | 2.8 kV |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
AK1301 Series
Enclosed, Conformal Coated DC DC Converter 1 Output 12V 10A 35V Input
