109E4712L401

Active

Sanyo Denki America Inc.

FAN AXIAL 172X25.4MM 12VDC WIRE

Search across all available documentation for this part.

Active

Sanyo Denki America Inc.

FAN AXIAL 172X25.4MM 12VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Specification	109E4712L401

Air Flow	4.54 mł/min
Air Flow	162 CFM
Approval Agency	CSA, TUV, UL
Bearing Type	Ball
Current Rating (Amps)	1 A
Fan Type	Tubeaxial
Features	Speed Sensor (Tach), Locked Rotor Protection
Lifetime @ Temp.	40000 Hrs
Material - Blade	Plastic
Material - Frame	Aluminum
Noise	48 dB
Operating Temperature [Max]	60 °C
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 °C
Operating Temperature [Min]	-20 C
Power (Watts)	12 W
RPM	2500 RPM
Size / Dimension	Rectangular/Rounded
Size / Dimension [x]	172 mm
Size / Dimension [y]	147 mm
Static Pressure	0.293 in H2O
Static Pressure	73 Pa
Termination	3 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.8 VDC
Voltage Range [Min]	10.2 VDC
Weight	500 g
Weight	1.1 lbs
Width [y]	25.4 mm

Part	Power (Watts)	Features	Weight	Weight	Air Flow	Air Flow	Termination	Noise	RPM	Width [y]	Fan Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension	Current Rating (Amps)	Voltage - Rated	Material - Blade	Voltage Range [Min]	Voltage Range [Max]	Material - Frame	Static Pressure	Static Pressure	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Lifetime @ Temp.	Bearing Type	Approval Agency
Sanyo Denki America Inc. 109E4712L4D01	12 W	Locked Rotor Sensor	500 g	1.1 lbs	4.54 mł/min	162 CFM	3 Wire Leads	48 dB	2500 RPM	25.4 mm	Tubeaxial	147 mm	172 mm	Rectangular/Rounded	1 A	12 VDC	Plastic	10.2 VDC	13.8 VDC	Aluminum	0.293 in H2O	73 Pa	60 °C	-20 °C	-20 C	60 °C	40000 Hrs	Ball	CSA TUV UL
Sanyo Denki America Inc. 109E4712L401	12 W	Locked Rotor Protection Speed Sensor (Tach)	500 g	1.1 lbs	4.54 mł/min	162 CFM	3 Wire Leads	48 dB	2500 RPM	25.4 mm	Tubeaxial	147 mm	172 mm	Rectangular/Rounded	1 A	12 VDC	Plastic	10.2 VDC	13.8 VDC	Aluminum	0.293 in H2O	73 Pa	60 °C	-20 °C	-20 C	60 °C	40000 Hrs	Ball	CSA TUV UL

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	16	$ 92.49

General part information

Fan Tubeaxial 12VDC Rectangular/Rounded - 172mm L x 147mm H Ball 162.0 CFM (4.54m³/min) 3 Wire Leads
