RFAA4NJNP

Active

BULGIN LIMITED

RF / COAXIAL ADAPTER, N, JACK, N, PLUG, STRAIGHT PANEL ADAPTER, 50 OHM

Search across all available documentation for this part.

Active

BULGIN LIMITED

RF / COAXIAL ADAPTER, N, JACK, N, PLUG, STRAIGHT PANEL ADAPTER, 50 OHM

Technical Specifications

Parameters and characteristics for this part

Specification	RFAA4NJNP

Adapter Series	N to N
Adapter Type	Plug to Jack
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Conversion Type	Same Series
Convert From (Adapter End)	N Jack, Female Socket
Convert To (Adapter End)	Male Pin, N Plug
Dielectric Material	Polyetherimide (PEI), Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	18 GHz
Impedance	50 Ohms
Mating Cycles	500
Mounting Feature	Flange
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Style	Straight

Part	Mounting Feature	Adapter Series	Style	Convert From (Adapter End)	Dielectric Material	Impedance	Body Material	Convert To (Adapter End)	Operating Temperature [Max]	Operating Temperature [Min]	Conversion Type	Adapter Type	Center Gender	Frequency - Max [Max]	Center Contact Material	Mating Cycles
BULGIN LIMITED RFAA4NJNJ	Flange	N to N	Straight	Female Socket N Jack	Polyetherimide (PEI) Polytetrafluoroethylene (PTFE)	50 Ohms	Stainless Steel	Female Socket N Jack	85 °C	-40 °C	Same Series	Jack to Jack	Female to Female	18 GHz	Beryllium Copper	500
BULGIN LIMITED RFAA4NJNP	Flange	N to N	Straight	Female Socket N Jack	Polyetherimide (PEI) Polytetrafluoroethylene (PTFE)	50 Ohms	Stainless Steel	Male Pin N Plug	85 °C	-40 °C	Same Series	Plug to Jack		18 GHz	Beryllium Copper	500

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 111.14
Newark	Each	1	$ 160.39

General part information

Adapter Coaxial Connector N Jack, Female Socket To N Plug, Male Pin 50 Ohms
