AA15S2400C

Obsolete

Delta Electronics

AC/DC CONVERTER 24V 15W

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC CONVERTER 24V 15W

Technical Specifications

Parameters and characteristics for this part

Specification	AA15S2400C

Applications	ITE (Commercial)
Approval Agency	CE
Efficiency	79 %
Features	Universal Input, DC Input Capable
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Power (Watts)	15 W
Size / Dimension [x]	74 mm
Size / Dimension [x]	2.91 "
Size / Dimension [y]	54 mm
Size / Dimension [y]	2.13 in
Size / Dimension [z]	0.77 "
Size / Dimension [z]	19.5 mm
Type	Enclosed
Voltage - Isolation	3000 V
Voltage - Output 1	24 V

Part	Power (Watts)	Load Regulation	Efficiency	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Standard Number	Line Regulation	Package / Case	Package / Case	Number of Outputs	Features	Weight	Weight	Type	Current - Output (Max) [Max]	Approval Agency	Current - Output 1	Voltage - Isolation
Delta Electronics AA15S1200A	15 W	0.5 %	79 %	ITE (Commercial)	-25 °C	70 °C	Through Hole	12 V	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in	60950-1	0.5 %	7-DIP Module	4 Lead	1	Universal Input	161.93 g	0.357 lb	Enclosed	1.25 A	CE cUL UL
Delta Electronics AA15S1200C	15 W		79 %	ITE (Commercial)	-25 °C	70 °C	Chassis Mount	12 V	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in					1	DC Input Capable Universal Input			Enclosed		CE	1.25 A	3000 V
Delta Electronics AA15S2400C	15 W		79 %	ITE (Commercial)	-25 °C	70 °C	Chassis Mount	24 V	74 mm	2.91 "	0.77 "	19.5 mm	54 mm	2.13 in					1	DC Input Capable Universal Input			Enclosed		CE		3000 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 24V 85 ~ 264 VAC Input
