1830867

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS IMCV 1,5/ 2-G-3 5 RN P20 THR

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS IMCV 1,5/ 2-G-3 5 RN P20 THR

Technical Specifications

Parameters and characteristics for this part

Specification	1830867

Color	Black
Contact Mating Finish	Tin
Current - IEC	8 A
Current - UL	8 A
Features	Locking Ramp
Header Orientation	Vertical
Housing Material	Liquid Crystal Polymer (LCP)
Insulation Height	0.569 in
Insulation Height	14.45 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Levels	1
Number of Positions	2
Pitch [x]	3.5 mm
Pitch [x]	0.138 in
Positions Per Level	2
Termination Style	Solder
Voltage - IEC	320 V
Voltage - UL	300 V

Pluggable Terminal Blocks 12 Pos 3.81mm pitch Thru Hole Invert Hdr

Part	Header Orientation	Material Flammability Rating	Features	Insulation Height	Insulation Height	Pitch [x]	Pitch [x]	Voltage - UL	Current - IEC	Number of Levels	Voltage - IEC	Mounting Type	Housing Material	Current - UL	Termination Style	Positions Per Level	Number of Positions	Contact Mating Finish	Color	Type	Contact Tail Length	Contact Tail Length
Phoenix Contact 1830867	Vertical	UL94 V-0	Locking Ramp	0.569 in	14.45 mm	3.5 mm	0.138 in	300 V	8 A	1	320 V	Through Hole	Liquid Crystal Polymer (LCP)	8 A	Solder	2	2	Tin	Black
Phoenix Contact 1875522	Vertical	UL94 V-0		0.571 in	14.5 mm	3.81 mm	0.15 in	300 V	8 A	1	320 V	Through Hole	Polyamide (PA) Nylon	8 A	Solder	12	12	Tin	Green	Header Female Sockets	3.4 mm	0.134 in
Phoenix Contact 1875519	Vertical	UL94 V-0		0.571 in	14.5 mm	3.81 mm	0.15 in	300 V	8 A	1	320 V	Through Hole	Polyamide (PA) Nylon	8 A	Solder	11	11	Tin	Green	Header Female Sockets	3.4 mm	0.134 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 12 Pos 3.81mm pitch Thru Hole Invert Hdr
