PEG220KL4270QE1
UnknownKEMET
CAP ALUM 2700UF 40V AXIAL TH
Deep-Dive with AI
Search across all available documentation for this part.
PEG220KL4270QE1
UnknownKEMET
CAP ALUM 2700UF 40V AXIAL TH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PEG220KL4270QE1 |
|---|---|
| Applications | Automotive |
| Capacitance | 2700 µF |
| ESR (Equivalent Series Resistance) | 39 mOhm |
| Lifetime @ Temp. | 2000 Hrs |
| Mounting Type | Through Hole |
| Package / Case | Axial |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Ripple Current @ High Frequency | 20.7 A |
| Ripple Current @ Low Frequency | 7.245 A |
| Tolerance [Max] | 30 % |
| Tolerance [Min] | -10 % |
| Voltage - Rated | 40 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 8.59 | |
| 10 | $ 7.45 | |||
| 75 | $ 6.68 | |||
| 150 | $ 5.80 | |||
Description
General part information
PEG220K Series
2700 µF 40 V Aluminum Electrolytic Capacitors Axial 39mOhm @ 100Hz 2000 Hrs @ 150°C
Documents
Technical documentation and resources
