09120013091

Active

HARTING Technology Group

CONN USB 2.0 TYPE A PL 2 POS ST CABLE MOUNT 1 PORT

Search across all available documentation for this part.

Active

HARTING Technology Group

CONN USB 2.0 TYPE A PL 2 POS ST CABLE MOUNT 1 PORT

Technical Specifications

Parameters and characteristics for this part

Specification	09120013091

Connector Type	Insert with USB
Gender	Female
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions	4
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Size	3 A
Termination Style	Crimp
Voltage Rating	50 V

Part	Connector Type	Housing Material	Gender	Material Flammability Rating	Voltage Rating	Size	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions	Termination Style
HARTING Technology Group 09120013071	Insert with Firewire	Polycarbonate (PC)	Female	UL94 V-0	50 V	3 A	85 °C	-40 °C	6	Crimp
HARTING Technology Group 09120013091	Insert with USB	Polycarbonate (PC)	Female	UL94 V-0	50 V	3 A	85 °C	-40 °C	4	Crimp

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Female Insert with USB 4 Position Crimp
